18-281/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
LMI Profile ID If the FRF.5 Over PNNI check box is selected (enabled),
select 1 or zero (0) for the LMI Profile ID. The default is
zero. Selecting 1 will signify this is an FRF.5 circuit.
Note – This LMI Profile ID must match the Terminating
Endpoint LMI Profile ID.
NNI DLCI If you enabled an LMI profile ID, you must specify the
NNI DLCI for the offnet circuit. The NNI DLCI can differ
from the DLCI configured at the UNI port. The LMI that
the NNI runs will use the NNI DLCI to identify the
network interworking PVC.
Enter an NNI DLCI within the valid range of 16 - 991 or
1022.
Notes: This NNI DLCI number must match the
Terminating Endpoint NNI DLCI number.
Review the Restrictions and Special Considerations
section of the Software Release Notice for CBX Switch
Software that comes with your release for information
about setting the NNI DLCI value.
Table 18-8. Add OffNet Circuit: FRF.5 Tab Fields (Continued)
Field Action/Description
Note – If enabled, the Reliable Scalable Circuit feature verifies the card state of
each Offnet PVC endpoint before sending the
SNMP Set command. If the card
status at either endpoint is not up, the NMS displays an error message indicating
where the failure occurred.
