3-61/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring CBX or GX Logical Ports
Working With ATM Logical Ports
To define the logical port for a GX 550 1-port OC-48c/STM-16c
module:
a. Expand the BIO-C card node, then expand the Subcards class node to display
the slots instance nodes.
b. Expand the slot node, then expand the PPorts class node and the PPort
instance node.
c. Expand the Subports class node, then the Subport instance node.
To define the logical port for a GX 550 ES switch:
a. Expand the GX 550 switch node in the lefthand side of the Navis EMS-CBGX
dialog box, then expand the Subcards class node to display the slot containing
the 1-port SW Down Link module.
b. Expand the PPorts class node, then the PPort instance node.
IMA group 3-port Channelized DS3/1
IMA IOM
1.
Expand the 3-port Channelized
DS3 ATM IMA instance node, then
expand the PPorts class node.
2. Expand the IMA Groups class
node, then the IMA group instance
node.
3-port Channelized
DS3/1 ATM w/IMA
Enhanced IOM
1-port Channelized
STM-1/E1 IMA IOM
1-Port Channelized
STM1/E1 ATM w/IMA
Enhanced
Module/Configuration Steps
Set
Note – See the Switch Module Configuration Guide for CBX 3500, CBX 500, GX 550,
and B-STDX 9000 for information about configuring physical port, channel, and IMA
group attributes for the following:
- CBX 500 — 3-port Channelized DS3/1 IMA IOM, 1-port Channelized STM-1/E1
IMA IOM
- CBX 3500 — 1-Port Channelized STM1/E1 ATM w/IMA Enhanced, 3-Port
Channelized DS3/1 ATM w/IMA Enhanced modules.
