Lucent Technologies MAX TNT - Page 101

Cabling and Connector Specifications
IDSL cable specifications
MAX TNT Hardware Installation Guide B-21
12 22 37 Ring 12
13 23 13 Tip 13
13 24 38 Ring 13
14 25 14 Tip 14
14 26 39 Ring 14
15 32 15 Tip 15
15 33 40 Ring 15
16 34 16 Tip 16
16 35 41 Ring 16
17 36 17 Tip 17
17 37 42 Ring 17
18 18 18 Tip 18
18 19 43 Ring 18
19 16 19 Tip19
19 17 44 Ring 19
20 14 20 Tip 20
20 15 45 Ring 20
21 12 21 Tip 21
21 13 46 Ring 21
22 10 22 Tip 22
22 11 47 Ring 22
23 8 23 Tip 23
23 9 48 Ring 23
24 6 24 Tip 24
24 7 49 Tip 24
14 1Tip1
Table B-19. IDSL cable pinouts (continued)
Pair P1 Pin P2 Pin P3 Pin J1 Pin J2 Pin Signal
