A-18 MAX TNT Hardware Installation Guide
Slot Card Specifications and Connection Information
MultiDSP cards
run both data and V.110, the ports on each installed 96-port MultiDSP card can handle data,
V.110 calls, or both.
Specifications
Table A-13 lists the specifications for the MultiDSP cards
Table A-13. MultiDSP card specifications
Category Specification
Physical interfaces 48 ports of supported application per 48-port MultiDSP card
96 ports of supported application per 96-port MultiDSP card
Power requirements 37W, 7.4A
Card weight ~1.5 pounds (0.7kg)
Hot swap capability Yes
Status light Multipurpose fault indicator, one per card
Operating humidity 10-90%, noncondensing
Operating temperature 32-104° F (0-40° C)
