A-14 MAX TNT Hardware Installation Guide
Slot Card Specifications and Connection Information
Ethernet-3 card
Ethernet-3 card
The Ethernet-3 card has a full-duplex 10/100Mbps Ethernet port that is designed to have a high
packet-per-second throughput to support Voice over IP (VoIP). The Ethernet-3 card autosenses
between 10Mbps and 100Mbps, but does not support autonegotiation, in which Ethernet
devices negotiate a common speed and duplex mode.
Specifications
Table A-9 lists the specifications for the Ethernet-3 card.
Status lights
Table A-10 explains the Ethernet-3 card status lights.
Table A-9. Ethernet-3 card specifications
Category Specification
Interfaces per card One full-duplex
Connector requirements Must meet Japanese Industrial Standards (JIS) C 5973
Card dimensions 5.6 inches high x 10.7 inches long (14.2cm x 27cm)
Card weight ~2 pounds (0.9kg)
Operating humidity 0-90%, noncondensing
Operating temperature 32-104° F (0-40° C)
Table A-10. Ethernet-3 card status lights
Light Color Description
A Yellow On indicates activity on 10Mbps link.
B Yellow On indicates connection to 10Mbps link.
C Green On indicates activity on 100Mbps link.
D Green On indicates connection to 100Mbps link.
