Cabling and Connector Specifications
Serial WAN (SWAN) cable specifications
Serial WAN cable
Figure B-11 and Table B-18 show the pinouts for the V.35 serial WAN (SWAN) cable.
Table B-18. Serial WAN cable pinouts
J1 Pin J2 Pin
46 A
42 D
43 E
35 C
34 H
33 F
16 B
44 K
16 B
18 T
17 R
28 S
27 P
20 X
19 V
26 W
25 U
24 Y
23 AA
