Slot Card Specifications and Connection Information
DS3-ATM card
DS3-ATM card
The DS3-ATM card (shown in Figure A-1) enables a MAX TNT unit to provide one active and
one standby trunk connection at data rates of 44.738Mbps. You can configure each port as one
of the following types of connections:
• User-to-Network Interface (UNI)
• Interim Inter-Switch Signaling Protocol (IISP) connection
• Direct trunk
One MAX TNT unit can accommodate a maximum of four DS3 ports (two active ports, two
standby ports).
Figure A-1. DS3-ATM card
Specifications
Table A-1 lists the specifications for the DS3-ATM card.
Table A-1. DS3-ATM card specifications
Category Specification
Agency approvals Electromagnetic Emissions Certifications: FCC Part 15
Class A, CISPR Class A
Interface standards ITU G.703
ANSI T1.102
Other standards supported ANSI T1E1.1/94-002R1
ANSI T1.107
ANSI T1.107a
ANSI T1.403
ATM Forum UNI 3.0/3.1
Bellcore TR-NWT 001112
Bellcore TR-TSY-000499
Bellcore TR-NWT-000820
ITU G.804
RFC 1407
TR54014 (AT&T ACCUNET T45 and T45R)
