B-14 MAX TNT Hardware Installation Guide
Cabling and Connector Specifications
E1/PRI interface specifications
E1/PRI straight-through cable: RJ-48C/Bantam
The WAN side of the RJ-48C/Bantam straight-through cable connects to dual bantam jacks.
Figure B-10 and Table B-14 show the pinouts.
Figure B-10. RJ-48C/Bantam straight-through cable
Table B-14. RJ-48C/Bantam straight-through cable specifications
Model number DBNT-RJ-48C
Part number 2510-0066-001
Pair # Signal Male RJ-48 Male Dual-310-P
(remote)
1 Receive 1
2
Tip 1
Ring 1
2Transmit5
4
Tip 2
Ring 2
