Slot Card Specifications and Connection Information
Ethernet-2 card
MAX TNT Hardware Installation Guide A-13
Ethernet-2 card
The Ethernet-2 card has three routed 10BaseT interfaces and one routed 100BaseT interface.
The card provides basic multisegment LAN-to-WAN access.
Figure A-10 shows the Ethernet-2 card.
Figure A-10. Ethernet-2 card
Table A-8 lists the specifications for the Ethernet-2 card.
Table A-8. Ethernet-2 card specifications
Category Specification
Power requirements 17W
Interfaces per card Three 10BaseT ports, one 100BaseT port
Connectors RJ-45
Connector requirements Must meet Japanese Industrial Standards (JIS) C 5973.
Card dimensions 8.8 inches high x 10.6 inches long (22.35cm x 26.92cm)
Card weight 3.9 pounds (1.77kg)
Operating humidity 10-90%, noncondensing
Operating temperature 32-104° F (0-40° C)
