Preparing for Installation
Understanding the unit’s back panel
Understanding the unit’s back panel
Figure 2-2 shows the back panel of a MAX TNT unit. The shelf controller is always slot 17.
The remaining slots are numbered 1 through 16. For information about installing a slot card in
a slot, see Chapter 3, “Installing a MAX TNT Chassis.”
Figure 2-2. Back panel of the MAX TNT
Slot 17
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
Slot 8
Slot 9
Slot 10
Slot 11
Slot 12
Slot 13
Slot 14
Slot 15
Slot 16
