Introduction
MAX TNT system overview
MAX TNT Hardware Installation Guide 1-3
Ethernet-3 ND 10/100Mbps Four autosensing 10/100Mbps
ports (RJ45 connectors).
Hybrid Access III N/A 186 ports.
MultiDSP (48 ports) N/A 48 ports that can be used as
voice ports, data ports, or
some combination of voice
and data ports.
MultiDSP (96 ports) N/A 96 data ports.
OC3-ATM 155.52Mbps One unchannelized OC-3 port.
Serial WAN (SWAN) 6Mbps to 8Mbps Four V.35 ports.
Series56 II Digital Modem 56Kbps 48 ports.
Series56 III Digital Modem 56Kbps 48 ports.
Synchronous Transport
Module 0 (STM-0)
51.85Mbps One fiber-optic connection.
T1 1.544Mbps Eight channelized ports.
T1 FrameLine 1.544Mbps 10 ports.
T3 (channelized) 44.736Mbps One active port and one
bypass port. Up to four active
ports per system.
Unchannelized DS3 44.736Mbps One active port. Up to five
active ports per system.
Table 1-1. MAX TNT slot cards and their port speeds and capacity (continued)
Card Port speed Port capacity
