LX iris EFIS
User inter face
Document name: LX HUM
Document revision: R1
User interface
4.1 Pages
To move through the pages, use left or right button, described in the section 4.1.1. The move-
ment though pages is circular, so it doesn’t matter in which direction pilot moves.
4.1.1 Pages overview
The primary pages represent a row of pages in the graphical user interface, which allow the
user to access different information screens and flight parameters.
The user will go through the following pages, in their respective order, if he swipes to the right
via right button.
Page Page Short
position name description
1 PFD page Attitude indicator with Airspeed and Altitude tape
2 APT navigation page Navigational page to a pilot selected airport
3 RTE navigation page Navigational page to a pilot defined route
4 G-force page G-force page with minimal, maximal and actual G load
5 Info page Info page with GPS, time, date and battery status
6 Logbook page* Pilots digital logbook with flight details and download
6 Statistics page* Flight statistics page will appear in flight after take-off
7 Airspace page Manage all active airspace
8 Setup page All settings and setup can be done here
*Logbook page is displayed while device is not in flight mode. Once device is in flight mode,
Statistics page will appear instead of Logbook.
Device manual Public 14
