LX iris EFIS
G-force page
Document name: LX HUM
Document revision: R1
G-force page
8.1 Overview
Figure 65. G-force page
G-force page delivers a super accurate G-force load applied to the pilot and aircraft.
At the top of the page if the actual G-force value.
On the left side pilot can see the “MIN” which is minimal G-force reached in the current flight.
On the right side pilot can see the “MAX” which is maximal G-force reached in the current
flight.
On the left side of the display pilot can see the Airspeed tape. To find out more refer to
“Airspeed tape” section of the manual.
Below is the TAS (True airspeed) information.
On the right side of the display pilot can see the “Altitude tape”. To find out more refer to “Altitude
tape” section of the manual.
Device manual Public 51
