2-109
Error code Details of failure Check items when failure occurs
EOO04L OR2 out-SOL Hi-error
・Check OR2 out-solenoid
・Check harness for circuit relating to OR2
out-solenoid
EOO04H OR2 out-SOL Lo-error
EOO05L OR3 in-SOL Hi-error
・Check OR3 in-solenoid
・Check harness for circuit relating to OR3
in-solenoid
EOO05H OR3 in-SOL Lo-error
EOO06L OR3 out-SOL Hi-error
・Check OR3 out-solenoid
・Check harness for circuit relating to OR3
out-solenoid
EOO06H OR3 out-SOL Lo-error
EOO07L OR4 in-SOL Hi-error
・Check OR4 in-solenoid
・Check harness for circuit relating to OR4
in-solenoid
EOO07H OR4 in-SOL Lo-error
EOO08L
OR4 out-SOL Hi-error
・Check OR4 out-solenoid
・Check harness for circuit relating to OR4
out-solenoid
EOO08H
OR4 out-SOL Lo-error
EOC01L Boom extension SOL Hi-error
・Check boom extension solenoid
・Check harness for circuit relating to boom
extension solenoid
EOC01H Boom extension SOL Lo-error
EOC02L Boom retraction SOL Hi-error
・Check boom retraction solenoid
・Check harness for circuit relating to boom
retraction solenoid
EOC02H Boom retraction SOL Lo-error
EOC03L Boom raising SOL Hi-error
・Check boom raising solenoid
・Check harness for circuit relating to boom raising
solenoid
EOC03H Boom raising SOL Lo-error
EOC04L Boom lowering SOL Hi-error
・Check boom lowering solenoid
・Check harness for circuit relating to boom
lowering solenoid
EOC04H Boom lowering SOL Lo-error
EOC05L
Winch wind-up SOL Hi-error
・Check winch wind-up solenoid
・Check harness for circuit relating to winch wind-up
solenoid
EOC05H
Winch wind-up SOL Lo-error
EOC06L Winch wind-down SOL Hi-error
・Check winch wind-down solenoid
・Check harness for circuit relating to winch
wind-down solenoid
EOC06H Winch wind-down SOL Lo-error
EOC08L Clockwise slewing SOL Hi-error
・Check clockwise slewing solenoid
・Check harness for circuit relating to clockwise
slewing solenoid
EOC08H Clockwise slewing SOL Lo-error
EOC07L Counterclockwise slewing SOL Hi-error
・Check counterclockwise slewing solenoid
・Check harness for circuit relating to
counterclockwise slewing solenoid
EOC07H Counterclockwise slewing SOL Lo-error
EO100H Fan stop output Hi-error
・Check harness for circuit relating to fan stop
output
EO100L Fan stop output Lo-error
EO101H
Electric stop output Hi-error
・Check harness for circuit relating to electric stop
output
EO101L
Electric stop output Lo-error
