E-12 [Surveillance cameras (forward / sideways) not displayed]
Content Surveillance cameras do not display
Assumed cause
and action to be
taken
Cause Diagnostic method and action to be taken
1
Open-circuit failure of
harness
(Open-circuit or connector
contact fault)
• Check that there are no open circuits in the surveillance
camera (forward / sideways) circuits
2
Harness short-circuit fault
(Contact with grounding
circuit)
• Check that there are no short circuits to ground in the
surveillance camera (forward / sideways) circuits
3
Defective surveillance
camera
• Check that the surveillance cameras (forward / sideways) are
functioning properly
4 Monitor fault
• When no problem is diagnosed in steps 1 to 3, it is likely that
the monitor is defective
E-13 [All operational machines / slewing / travelling do not function]
If an error code is displayed, prioritize the diagnosis and countermeasures for it.
Content None of all the working machines and the slewing/travelling works
Assumed cause
and action to be
taken
Cause Diagnostic method and action to be taken
1 Locking lever switch fault
• Check to make sure that the locking lever is not in free
position.
• Check if the micro switch functions properly.
2
Open-circuit failure of
harness
(Open-circuit or connector
contact fault)
• Check locking lever signal circuit for open circuits
3
Harness short-circuit fault
(Contact with grounding
circuit)
• Check that there are no short circuits to ground in the locking
lever signal circuit
4
Is the emergency stop switch
functioning?
• Cancel the emergency stop switch
E-14 [Travelling speed cannot be changed]
If an error code is displayed, prioritize the diagnosis and countermeasures for it.
Content Switching travel speeds does not change the travelling speed.
Assumed cause
and action to be
taken
Cause Diagnostic method and action to be taken
1 Left side joystick switch fault
• In travelling mode, the Hi-Lo travelling changeover switch on
the left side joystick switch (front left switch) is defective
2
2-speed travelling switching
solenoid is defective
• Check if 2-speed travelling switching solenoid (travel speed
switching valve) functions properly
3
Open-circuit failure of
harness
(Open-circuit or connector
contact fault)
• Check that there are no open circuits in the circuits relating to
the 2-speed travelling switching solenoid / left side joystick
switch
4
Harness short-circuit fault
(Contact with grounding
circuit)
• Check that there are no short circuits to ground in the circuits
relating to the 2-speed travelling switching solenoid / left side
joystick switch
5 Monitor fault
• When no problem is diagnosed in steps 1 - 4, it is likely that the
monitor is defective
6 Controller fault
• If there is still no problem diagnosed in steps 1 - 5, a fault in the
controller (TTC540) is possible
