Maeda MC815C - Hydraulic Piping Rotating Part Assembly (Derricking Lines)

2-80
4.20.7 HYDRAULIC PIPING ROTATING PART ASSEMBLY (DERRICKING LINES)
Equipment
name
Port
Joint Hose/Piping Joint
Port
Connection
destination
No.
Name
No.
Name
No.
Name
Part No. Part No. Part No.
Rotary joint
(106-2178500)
F (7)
Male 90° elbow with
plate
1
DA2 hose
(2)
Mail 90° elbow with long plate
A
Raising
counterbalance
(106-3394000)
22611-1115
6
[1071-08-06 HYDEX]
106-4672200
[KG06-C-C-1070L]
22611-12250
[1071-0674A HYDEX]
D (7)
Male 90° elbow with
plate
2
DB2 hose
(2)
Mail 90° elbow with
long plate
B
Lowering
counterbalance
(106-3394000)
22611-1115
6
[1071-08-06 HYDEX]
106-4672300
[KG06-C-C-1200L]
22611-12250
[1071-0674A HYDEX]
Figures in No. parentheses ( ) refer to equipment names, and connection point parentheses ( ) to part numbers
106-1183000 - Derricking
