1-22
8. WORKING RADIUS AND HOISTING HEIGHT (TRAVELLING WITH
HOISTED LOAD)
In cases where travelling with hoisted load cannot be avoided, follow the rules below to prevent the
machine from overturning.
1. Do not travel on slopes, soft ground, or ground that is not flat.
2. Do not perform slewing operations. Avoid performing sudden operations when stopping or starting.
3. When travelling with hoisted load, do so with the load close to the ground as far as is possible.
4. If the hoisted load swings, stop travelling until the hoisted load settles.
