2-138
9.3.4 PRESSURE SENSOR
Specifications
Pressure range 0 to 35 MPa
Pressure resistance 70 MPa
Power supply voltage 12 VDC ± 10%
Output type 1 to 5 VDC 3-wire system
Mechanical accuracy ±0.25% FS (Overall value for non-linearity, hysteresis, and reproducibility)
Mechanical stability ±0.2% FS (10,000,000 cycles / after full scale pressure application operation)
Temperature
characteristics
± 1.5% FS / 100 °C
Operating temperature
-40 to + 105 °C
S106J3598000
To Next Page
