Maeda MC815C - Selector Valve Block (Fly Jib Telescopic Cylinder Mounted)

5-7
2.5 SELECTOR VALVE BLOCK (FLY JIB TELESCOPIC CYLINDER MOUNTED)
Specifications
Maximum service pressure 20.6 MPa
Maximum service flow rate 45 L/min
Allowable temperature range -10 to 90 °C
Solenoid operated directional
control valve
Electrical specifications
Rated voltage 12 VDC (Continuous rating)
Holding current 2.6 A (at rated voltage)
Holding power 31 W (at rated voltage)
Connector DT04-2P (DEUTSCH)
S106G3800000
