Maeda MC815C - Eot01 H; Eot01 L; Eot02 H; Eot02 L

T-344
Error code [EOT01H] Travelling forward left SOL Lo-error
Error code EOT01H
Details of
failure
Forward left SOL Lo-error
Failure-determining
conditions
Solenoid resistance undershot 4 Ω (when output is ON).
Short circuit to power supply line detected (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Harness short circuit to
power supply line
Check the related circuits for any short circuit to ground.
2 Forward left SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOT01L] Travelling forward left SOL Hi-error
Error code EOT01L
Details of
failure
Forward left SOL Hi-error
Failure-determining
conditions
Solenoid resistance exceeded 20 kΩ (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Open circuit in harness
related to forward left SOL
Check the related circuits for any open circuit.
2 Forward left SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOT02H] Travelling backward left SOL Lo-error
Error code EOT02H
Details of
failure
Backward left SOL Lo-error
Failure-determining
conditions
Solenoid resistance undershot 4 Ω (when output is ON).
Short circuit to power supply line detected (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Harness short circuit to
power supply line
Check the related circuits for any short circuit to ground.
2 Backward left SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOT02L] Travelling backward left SOL Hi-error
Error code EOT02L
Details of
failure
Backward left SOL Hi-error
Failure-determining
conditions
Solenoid resistance exceeded 20 kΩ (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Open circuit in harness
related to backward left SOL
Check the related circuits for any open circuit.
2 Backward left SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
