Maeda MC815C - Slide Cylinder Connection Destinations; Slide Cylinder Specifications

2-62
4.16.2 SLIDE CYLINDER CONNECTION DESTINATIONS
Port
name
Port destination Port size Note:
A OR select valve C4 port G1/4 Extension
B OR select valve C1 port G1/4 Contraction
4.16.3 SLIDE CYLINDER SPECIFICATIONS
Size 75 ×50 - 856 st
Service pressure
Extension
side
20.6 MPa
Retracting
side
20.6 MPa
Normal load
When
extended
91.0 KN
When
retracted
50.6 KN
