Maeda MC815C - Telescopic Cylinder Connection Destinations; Telescopic Cylinder Specifications

2-52
4.14.2 TELESCOPIC CYLINDER CONNECTION DESTINATIONS
Port name Port destination Port size Note:
A Rotary joint E port G3/8 Extension
B Rotary joint C port G3/8 Contraction
4.14.3 TELESCOPIC CYLINDER SPECIFICATIONS
Service pressure
Extension
side
20.6 MPa
Retracting
side
20.6 MPa
No. 1 cylinder size
95 ×80 - 3470 st
Normal load
When
extended
146.0 KN
When
telescoping
42.5 KN
No. 2 cylinder size
80 ×65 - 3470 st
Normal load
When
extended
103.5 KN
When
telescoping
35.2 KN
No. 3 cylinder size 80 ×65 - 3470 st
Normal load
When
extended
103.5 KN
When
telescoping
35.2 KN
