Maeda MC815C - MOMENT LIMITER CONFIGURATION

2-83
4.20.10 HYDRAULIC PIPING ROTATING PART ASSEMBLY (WINCH DRAIN LINE)
Equipment
name
Port
Joint Hose/Piping Joint
Port
Connection
destination
No.
Name
No.
Name
No.
Name
Part No. Part No. Part No.
Rotary joint
(106-2178500)
DR (24)
Single male threaded
tee
22031-36500
[2092-06 HYDEX]
(25)
Male connecto
r
10
WDR hose
22611-10150
[1009-06 HYDEX]
106-4671200
[KF06-C-C-1820L]
16
W drain pipe
(45)
Flareless type joint
D
Winch motor
(106-1189100)
106-3365900
22511-07660
[LLM-UR-15×1]
Figures in No. parentheses ( ) refer to equipment names, and connection point parentheses ( ) to part numbers
106-1183000 - Winch drain
