Maeda MC815C - Outrigger Cylinder Connection Destinations; Outrigger Cylinder Specifications

2-59
4.15.2 OUTRIGGER CYLINDER CONNECTION DESTINATIONS
Port
name
Port destination Port size Note:
A OR select valve C3 port G1/4 Extension
B OR select valve C2 port G1/4 Contraction
4.15.3 OUTRIGGER CYLINDER SPECIFICATIONS
Size 140 ×80 - 302 st
Service pressure
Extension
side
20.6 MPa
Retracting
side
20.6 MPa
Normal load
When
extended
317.1 KN
When
retracted
213.6 KN
