Maeda MC815C - Eoo07 H; Eoo07 L; Eoo08 H; Eoo08 L

T-340
Error code [EOO07H] OR4-in SOL Lo-error
Error code EOO07H
Details of
failure
OR4-in SOL Lo-error
Failure-determining
conditions
Solenoid resistance undershot 4 Ω (when output is ON).
Short circuit to power supply line detected (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Harness short circuit to
power supply line
Check the related circuits for any short circuit to ground.
2 OR4-in SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOO07L] OR4-in SOL Hi-error
Error code EOO07L
Details of
failure
OR4-in SOL Hi-error
Failure-determining
conditions
Solenoid resistance exceeded 20 kΩ (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Open circuit in harness
related to OR4-in SOL
Check the related circuits for any open circuit.
2 OR4-in SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOO08H] OR4-out SOL Lo-error
Error code EOO08H
Details of
failure
OR4-out SOL Lo-error
Failure-determining
conditions
Solenoid resistance undershot 4 Ω (when output is ON).
Short circuit to power supply line detected (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Harness short circuit to
power supply line
Check the related circuits for any short circuit to ground.
2 OR4-out SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOO08L] OR4-out SOL Hi-error
Error code EOO08L
Details of
failure
OR4-out SOL Hi-error
Failure-determining
conditions
Solenoid resistance exceeded 20 kΩ (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Open circuit in harness
related to OR4-out SOL
Check the related circuits for any open circuit.
2 OR4-out SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
