Maeda MC815C - Eoo05 H; Eoo05 L; Eoo06 H; Eoo06 L

T-339
Error code [EOO05H] OR3-in SOL Lo-error
Error code EOO05H
Details of
failure
OR3-in SOL Lo-error
Failure-determining
conditions
Solenoid resistance undershot 4 Ω (when output is ON).
Short circuit to power supply line detected (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Harness short circuit to
power supply line
Check the related circuits for any short circuit to ground.
2 OR3-in SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOO05L] OR3-in SOL Hi-error
Error code EOO05L
Details of
failure
OR3-in SOL Hi-error
Failure-determining
conditions
Solenoid resistance exceeded 20 kΩ (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Open circuit in harness
related to OR3-in SOL
Check the related circuits for any open circuit.
2 OR3-in SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOO06H] OR3-out SOL Lo-error
Error code EOO06H
Details of
failure
OR3-out SOL Lo-error
Failure-determining
conditions
Solenoid resistance undershot 4 Ω (when output is ON).
Short circuit to power supply line detected (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Harness short circuit to
power supply line
Check the related circuits for any short circuit to ground.
2 OR3-out SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
Error code [EOO06L] OR3-out SOL Hi-error
Error code EOO06L
Details of
failure
OR3-out SOL Hi-error
Failure-determining
conditions
Solenoid resistance exceeded 20 kΩ (when output is OFF).
Assumed cause and
diagnostic method
Cause Diagnostic method and action to be taken
1
Open circuit in harness
related to OR3-out SOL
Check the related circuits for any open circuit.
2 OR3-out SOL fault Check if the solenoid functions normally.
[Additional information] Refer to T-346 for relevant electric circuit and T-347 for location
