MAHA POWERDYNO MSR Series User Manual

121
BA053101-en
LED
Color
Status
Description, Cause
Remedy
DP1
PROFIdrive
cyclic opera-
tion
- Off
Cyclic communication has not (yet) taken
place.
Note:
PROFIdrive is ready for communication
when the Control Unit is ready (see LED
RDY).
-
Green
Steady
light
Cyclic communication is taking place. -
Flashing
0.5 Hz
Full cyclic communication is not yet taking
place.
Possible causes:
• The controller is not transmitting set-
points.
• During isochronous operation, not global
control (GC) or a faulty global control
(GC) is transferred by the Controller.
-
Red
Steady
light
Cyclic communication has been interrupted. Remedy fault
OPT
(OPTION)
- Off
Electronics power supply is missing or out-
side permissible tolerance range.
Module is not ready.
Option board not installed or no associated
drive object has been created.
-
Green
Steady
light
Option board is ready. -
Flashing
0.5 Hz
Depends on the option board used. -
Red
Steady
light
At least one fault is present in this module.
Option board not ready (e.g. after power-
on).
Remedy and
acknowledge fault
MOD - Off Reserved -
