Process Profile

1 Call up the menu DATABASE and dthen the

menu point LOAD SIMULATION PROFILE:

 The database browser appears.

2 Select a profile with the cursor key or the

mouse.

3 Open the profile by double clicking or press

the <ENTER> key.

The screen for the profile setting appears

4 Enter the changes. Select the boxes and

enter the desired values.

5 The changes are displayed with <F6 IM-

PORT>.

6 The changes are stored with <F8 STORE>.

Export Profile

See paragraph "

Identical Functions

", function "

Export"

Import Profile

See paragraph "

Identical Functions

", function "

Import"

Pos: 339 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1.1/ F/Übersc hrift 1 .1.1: F ahrzy klus-Dat en @ 13\mod_1234863000076_75.docx @ 3408 43 @ 3 @ 1

11.1.6

Driving Cycle Data

Pos: 340 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 523 01 LPS 3 000 R10 0/B A/I nhal t: 052 3 Fahr zy klus -Daten @ 1 3\mod_1234863045373_75.docx @ 340869 @ @ 1

1 Call up the menu DATABASE and then the

menu point DRIVING CYCLE:

 The database browser appears.

2 Select a dataset with the cursor key or the

mouse.

3 Open the dataset by double clicking or press

the <ENTER> key.

 The measurement screen appears.
