MAHA POWERDYNO MSR Series User Manual

123
BA053101-en
Pos: 427 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1/S/ Überschr ift 1 .1: Sin gle Mo tor Modu le / D ouble M ot or M od ule / Pow er M od ule @ 1 7\mod _12 53261 4155 75_75.d ocx @ 44 4618 @ 2 @ 1
16.3
Single Motor Module / Double Motor Module
Pos: 428 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 531 01 M SR/ BA/I nha lt: 053 1 SIN AMI CS Smar t L ine Modu le 16 k W un d 3 6 k W / S ingl e M ot or Mod ule @ 17\mod_1253259413890_75.docx @ 444591 @ @ 1
Status
Description, Cause
Remedy
Ready
(H200)
DC link (H201)
Off Off
Electronics power supply is missing or outside per-
missible tolerance range.
-
Green
Off
The component is ready for operation and cyclic
DRIVE-CLliQ communication is taking place.
-
Orange
The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is present.
-
Red
The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is too high.
Check supply voltage
Orange Orange DRIVE-CLiQ communication is being established. -
Red -
At least one fault is present in this component.
Note
:
LED is driven irrespective of the corresponding mes-
sages being reconfigured.
Remedy and
acknowledge fault
Green / Red - Firmware is being downloaded. -
Green /
Orange
or
Red / Orange
-
Component recognition via LED is activated
(Ip0124).
Note
:
Both options depend on the LED status when com-
ponent recognition is activated via p0124 = 1.
-
Hazard DC link voltages may be present at any time regardless of the status of the "DC link" LED.
The warning information on the components must be carefully observed!
Pos: 429 /-----F ormat- ----/MA NUELLE R UMBR UCH Seitenum bruch @ 0\mod_1134403577687_0.docx @ 1277 @ @ 1
