16.2
Smart Line Module 16kW and 36kW
Pos: 425 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 531 01 M SR/ BA/I nha lt: 053 1 SIN AMI CS Smar t L ine Modu le 16 k W und 36 k W / S in gle M ot or Mod ule @ 17\mod_1253259413890_75.docx @ 444591 @ @ 1
Status
Description, Cause
Remedy
Ready
(H200)
DC link (H201)
Off Off
Electronics power supply is missing or outside per-
missible tolerance range.
-
Green
Off
The component is ready for operation and cyclic
DRIVE-CLliQ communication is taking place.
-
Orange
The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is present.
-
Red
The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is too high.
Check supply voltage
Orange Orange DRIVE-CLiQ communication is being established. -
Red -
At least one fault is present in this component.
Note
:
LED is driven irrespective of the corresponding mes-
sages being reconfigured.
Remedy and
acknowledge fault
Green / Red - Firmware is being downloaded. -
Green /
Orange
or
Red / Orange
-
Component recognition via LED is activated
(Ip0124).
Note
:
Both options depend on the LED status when com-
ponent recognition is activated via p0124 = 1.
-
Hazard DC link voltages may be present at any time regardless of the status of the "DC link" LED.
The warning information on the components must be carefully observed!
