Sensor Module Cabinet 30 (SMC30)
Pos: 431 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 531 01 M SR/ BA/I nha lt: 053 1 SIN AMI CS Sen sor M od ule C ab ine t 3 0 (SMC 30) @ 17\mod_1253261947128_75.docx @ 444732 @ @ 1
LED
Color
Status
Description, Cause
Remedy
RDY
READY
- Off
Electronics power supply is missing or outside
permissible tolerance range.
-
Green
Steady
light
The component is ready for operation and cy-
clic DRIVE-CLiQ communication is taking place.
-
Orange
Steady
light
DRIVE-CLiQ communication is being estab-
lished.
-
Red
Steady
light
At least one fault is present in this component.
Note
:
LED is driven irrespective of the corresponding
messages being reconfigured.
Remedy and ack-
nowledge fault
Green / Red Flashing Firmware is being downloaded. -
Green /
Orange
or
Red / Orange
Flashing
Component recognition via LED is activated
(p0144).
Note
:
Both options depend on the LED status when
component recognition is activated via p0144 =
1.
-
OUT > 5V
- Off
Electronics power supply is missing or outside
permissible tolerance range.
Power supply > 5 V.
-
Orange
Steady
light
Electronics power supply for measuring system
available.
Power supply > 5 V.
Notice:
You must ensure that the connected encoder
can be operated with a 24 V supply. If an en-
coder that is designed for a 5 V supply is oper-
ated with a 24 V supply, this can destroy the
encoder electronics.
-
