8.7
Bring the Vehicle up to Operating Temperature
Pos: 225 /Tech nische D okumen tation/ Leistu ngsmess techni k/POWE RDYN O/0 523 01 LP S 3 000 R10 0/B A/I nha lt: 052 3 Fahr ze ug auf B etr ieb stem per atur br inge n @ 13\m od_1234342622317_75.docx @ 338415 @ @ 1
This can be done using the load simulation, e.g. with a constant traction (see section "Load
Simulation"
).
Pos: 226 /Te chnis che D okumen tation/A lle G eräte/ Überschr iften/Üb erschr iften 1 .1/F/ Übersc hrift 1.1 : Fahrz eug p rüfber eit @ 13\mod_1234342668088_75.docx @ 338441 @ 2 @ 1
8.8
Vehicle Ready for Testing
Pos: 227 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 523 01 LPS 3 000 R10 0/B A/In hal t: 05 23 F ahr ze ug pr üfb ere it @ 13\m od_1234342707843_75.docx @ 338467 @ @ 1
The vehicle is ready for testing when all the preparation steps for testing have been completed.
Pos: 228 /Tech nische D okumen tation/ Leistu ngsmess techni k/- Arch iv -/00 LPS Alle/Inhalte/Warnung!/Inhalt: Warnung - Lebens gefahr durc h rotierende Prüfs tandsroll en @ 14\mod_1241613428231_75.docx @ 372059 @ @ 1
Life-threatening injuries possible by rotating dyno rollers!
•
Always
keep body parts and clothing far away from rotating rollers, as there is danger of these
being pulled into the rotating rollers!
• Safeguard that the operating personnel is informed when someone is underneath the dyno.
Danger for those who are under the dyno without the knowledge of the operating personnel!
• If this safety system has been bypassed, the service personnel is responsible for establishing
necessary and suitable safety measures (e.g. signs which indicate that service work is being
done).
• Make sure that all keys for bypassing safety systems are only available to specially trained ser-
vice personnel.
•
Do not
leave the keys in the key switch during normal test operation.
Pos: 229 /Tech nische D okumen tation/ Leistu ngsmess techni k/- Ar chiv -/00 LPS A lle/In ha lte/War nun g!/In halt: Warnung - Gefahr v on G ehörsch äden @ 14\mod_1241613590981_75.docx @ 372085 @ @ 1
Risk of hearing damage due to high noise level!
• Use ear protection which is approved for up to 120 dB(A).
Noise levels of over 100 dB(A) are possible during vehicle testing.
Pos: 230 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1/P/ Überschr ift 1 .1: Prüfs tand verlass en @ 14\mod _124 16137 39500_ 75.d ocx @ 37 2111 @ 2 @ 1
8.9
Exit the Dynamometer
Pos: 231 /Te chnis che Dok umen tati on/ Leistu ngsm esst echni k/PO WER DYNO/ 053 101 M SR/ BA/Inh alt: 0531 P rüf stand verl asse n @ 1 4\mod_1241613800337_75.docx @ 372147 @ @ 1
1 Block the rollers.
2 Remove the roller adjustment device from the rear axle in a backward direction.
3 Shift into 1st gear and put on the parking brake.
4 Loosen the tightening straps at the front axle.
5 Then loosen the tightening straps at the rear axle.
6 Remove all tightening straps.
7 Release parking brake and shift into idle.
8 Drive vehicle off dyno.
