Diagnosis of SINAMICS Components
Pos: 421 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1/L/ Übersc hrift 1 .1: LEDs nach d em H ochlau f der Control Unit CU320 @ 17\mod_1253255673954_75.docx @ 444 510 @ 2 @ 1
16.1
LEDs after the Control Unit has booted
Pos: 422 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 531 01 M SR/ BA/I nha lt: 053 1 SIN AMI CS LE Ds na ch d em H oc hla uf d er C ont ro l Un it C U32 0 @ 17\mod_1253255768591_75.docx @ 444537 @ @ 1
LED
Color
Status
Description, Cause
Remedy
RDY
(READY)
- Off
Electronics power supply is missing or out-
side permissible tolerance range.
-
Green
Steady
light
The module is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
-
Flashing
2 Hz
Writing to CompactFlash cord. -
Red
Steady
light
At least one fault is present in this module.
Remedy and acknow-
ledge fault
Flashing
0.5 Hz
Boot error.
Check whether Com-
pactFlash card is
plugged in correctly
Replace CompactFlash
card
Replace Control Unit
Carry-out a POWER ON
Green /
Red
Flashing
0.5 Hz
Control Unit 320 is ready.
No software licenses.
Obtain licenses
Orange
Steady
light
DRIVE-CLiQ communication is being estab-
lished.
-
Flashing
0.5 Hz
Unable to load firmware to RAM.
Check whether Com-
pactFlash card is
plugged in correctly
Replace CompactFlash
card
Replace Control Unit
Carry-out a POWER ON
Flashing
2 Hz
Firmware CRC error.
Check whether Com-
pactFlash card is
plugged in correctly
Replace CompactFlash
card
Replace Control Unit
Carry-out a POWER ON
