Use this menu point to test the vehicle’s speedometer. The following functions can be checked.
• Vehicle speed
• Mileage
Pos: 306 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1.1/ F/Übersc hrift 1 .1.1: F ahrzeu g-Gesch windigke it @ 13\mod_ 12347 83560 798_7 5.do cx @ 340 297 @ 3 @ 1
Pos: 307 /Tech nische D okumen tation/ Leistu ngsmess technik/POWERDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 Fahrzeug-Gesc hwi ndigke it @ 13\mod_1234783610519_75.docx @ 340323 @ @ 1
Ten freely selectable speedometer target speeds can be entered using this menu point. Each one
can be approached, one after another. A basic setting is done at dyno configuration.
1 Position the vehicle on the dyno and fix it.
2 Call up the menu SPEEDOMETER TEST and
then the menu point VEHICLE SPEED.
The following screen appears:
3 Use the key <F6 PROCESS> to change the
target speeds.
The value
shows the current speed of
the vehicle on the rollers. The target speed
must be approached with the vehicle
speedometer.
4 Use the button<F8 CONTINUE>.
5 Accelerate the vehicle to the target speed.
Base it on the vehicle speedometer.
6 If the speed is held constant for 3 seconds,
the value is automatically taken over. Other-
wise store the measurement value with <F8
CONFIRM>.
The display jumps to the next target speed.
7 Repeat the test for each target speed.
Use the <F5 RETURN> to jump back to the previous target speed.
Use the <F7 PASS OVER> key to jump to the next target speed.
