MAHA POWERDYNO MSR Series User Manual

61
BA053101-en
Pos: 216 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1/Ö/ Übers chrift 1.1: Öltemper aturso nde ansc hließe n @ 13\mod_1234341805123_75.docx @ 338233 @ 2 @ 1
8.4
Connect Oil Temperature Probe
Pos: 217 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 523 01 LPS 3 000 R10 0/B A/I nhal t: 052 3 Ölt emp era turs onde anschli eßen @ 13\mod_1234342041226_75.docx @ 338259 @ @ 1
1 Remove the oil dipstick from the engine.
2 Adjust the length of the oil temperature probe to the length of the original dipstick by using the
cone plug.
Risk of damage!
Incorrect length adjustment of the oil temperature probe can lead to engine damage!
3 Replace the oil dipstick with the oil temperature probe. Close the opening with the cone plug.
Pos: 218 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1/A/ Überschr ift 1 .1: Abg asablei tung anb rin gen @ 1 3\mod_ 123 43422 18504 _75.d ocx @ 338 285 @ 2 @ 1
8.5
Attach Exhaust Suction System
Pos: 219 /Tech nische D okumen tation/ Leistu ngsmess techni k/- Ar chiv -/00 LPS Alle/Inhalte/Warnung!/Inhalt: Warnung - Ve rg iftun gsgefa hr d urc h Ab gase im Pr üfraum @ 18\mod_1253777830063_75.docx @ 447690 @ @ 1
Danger of poisoning by exhaust gases in the test room!
• Use an exhaust suction system.
Pos: 220 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 523 01 LPS 3 000 R10 0/B A/In hal t: 05 23 A b gasab le itun g a nbrin ge n @ 1 3\mod_1234342301908_75.docx @ 338311 @ @ 1
1 Place the exhaust suction system close to the exhaust pipe and switch it on.
Risk of damage!
A certain distance should be maintained from the vehicle because of possible heat accumulation in
the exhaust suction unit which may cause damage to vehicle or paint.
Pos: 221 /Tech nische D okumen tation/A lle G eräte/ Überschr iften/Üb ers chrifte n 1.1/K/ Übersc hrift 1 .1: Küh lluftgeb läse p ositio nieren @ 1 3\mod_ 1234 342 379 952_7 5.doc x @ 33833 7 @ 2 @ 1
8.6
Position Cooling Air Fan
Pos: 222 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 523 01 LPS 3 000 R10 0/B A/I nhal t: 052 3 Küh lluf tgeb läs e p osit ionier en @ 13\mod_1234342425246_75.docx @ 338363 @ @ 1
1 Position the cooling air fan in front of the vehicle’s radiator.
2 To make sure that the fan remains in place during operation, use the fixing levers on the casters
of the fan.
3 Switch on the air cooling fan.
Risk of damage!
Cables and tightening straps can get between tires and rollers due to the air flow.
Pos: 223 /-----F ormat- ----/MA NUELLE R UMBR UCH Seitenum bruch @ 0\mod_1134403577687_0.docx @ 1277 @ @ 1
