DRZ
A
Piezo clamp, TDC sensor Light barrier
B
Piezo clamp, TDC sensor Light barrier
C
Oil temperature probe
D
Trigger tongs
PTH
E
Fuel temperature
F
Intake air temperature
G
Atmospheric pressure
H
Humidity sensor
OBD (Option)
I
OBD
P2T2 (Option)
J
Pressure 1
K
Pressure 2
L
Temperature 1
M
Temperature 2
Pos: 106 /Te chnis che D okum ent ati on/ Leis tun gsm esst ech nik/ POWE R DYN O/0 523 01 LPS 3 000 R10 0/B A/I nhal t: 052 3 Sch ni ttste lle nbox- Bele gung (Te xt) @ 13\m od_1234253839295_75.docx @ 336327 @ @ 1
Display the Interface Box Assignment
1 The assignment of the interface box appears using the keys <SHIFT> + <F1> .
2 Use <CONTINUE> or <RETURN> to exit this screen.
