BA053101-en
Dyno is set for CAR (green).
Fan (red: switched off
green: switched on)
Pneumatic holding brake of dyno rollers.
Green: Brake of drive axle(s) selected is open – rollers can rotate freely.
Red: All brakes are closed – rollers are blocked.
Yellow: Position of brakes is not compatible with vehicle. Click on the symbol to
close the brakes: "red". Click again to open the brakes: "green".
Front Wheel Drive mode
Rear Wheel Drive mode
4 Wheel Drive mode
For setting a speed difference (3 % max.) between HA (rear wheel drive) and FA
(front wheel drive)
