Maintenance work on the carrier
7.6 Transmission
7 - 46 3 302 756 en Maintenance manual
GMK6400
16.11.2018
Draining oil
• Place a receptacle underneath the screw (2)
on the transmission.
• Unscrew bolts (1) and (2) and allow the oil to
drain.
• Clean the drain plugs.
• Replace the seal and tighten the drain
plug
(2) to a torque of 60 Nm (44.2 lbf ft).
G
Risk of scalding from gear oil at operating temperature!
You could scald yourself by gear oil escaping in an uncontrolled manner at
operating temperature. Wear appropriate protective gloves and take care
not to come into contact with the gear oil.
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
