Table 2-6. Manual Mode (On/Off) Select
Manual Mode On/Off – LED 3 Blinking Slowly
LED MODE
12 N/A
11 N/A
10 N/A
9 N/A
8 N/A
7 N/A
6 N/A
5 N/A
4 N/A
3 N/A
2 ON
1 OFF
Table 2-7. Manual Mode (If – Limit) Adjustment Ranges
Manual Mode Adjust – LED 4 Blinking Slowly
Adjustment Range: 0 to 3 Adc
Increment: 0.01 Adc
LED Minimum Value Maximum Value
12 2.75 3
11 2.50 2.74
10 2.25 2.49
9 2.00 2.24
8 1.75 1.99
7 1.50 1.74
6 1.25 1.49
5 1.00 1.24
4 0.75 0.99
3 0.50 0.74
2 0.25 0.49
1 0 0.24
Table 2-8. On-Line Operating Mode (AVR (OFF)/VAR/PF) Select *
AVR (OFF) / VAR / PF Select – LED #5 Blinking Slowly
LED MODE
12 N/A
11 N/A
10 N/A
9 N/A
8 N/A
7 N/A
6 N/A
5 N/A
4 N/A
3 Var
2 PF
1 AVR
* Var/PF control is available only on DVR2000EC.
