A setting is changed by clicking within the setting eld and typing the new setting. The range limit of a setting can
be viewed by double-clicking the setting. Any setting changes made on a setting group screen must be sent to
the DVR2000E before viewing other screens. Otherwise, the setting changes will be lost. A single setting change
can be sent to the DVR2000E by pressing the Enter key on your PC keyboard. Multiple setting changes can be
sent to the DVR2000E by clicking the SendToDVR button. Settings can also be sent to the DVR2000E by clicking
Communications on the menu bar and clicking Send To DVR.
SENDING AND RECEIVING SETTINGS
When communication is enabled, DVR2000E settings can be sent or received through
MARATHON-DVR2000E-32.
Sending Settings
Settings changes are sent to the DVR2000E by clicking the SendToDVR button. This causes the settings displayed
on the current settings screen to become the DVR2000E settings. Settings can also be sent to the DVR2000E by
clicking Communications on the menu bar and clicking Send To DVR. Individual setting changes can be sent to
the DVR2000E by pressing the Enter key on your PC keyboard after changing the setting.
Receiving Settings
DVR2000E settings are retrieved by clicking the GetFromDVR button. This causes the DVR2000E settings to be
displayed on the settings screen. Settings can also be received from the DVR2000E by clicking Communications
on the menu bar and clicking Get From DVR.
Saving Settings to DVR2000E Memory
Settings are saved in nonvolatile memory (EEPROM). In the event of a power loss, these are the settings that are
active at power up. If settings are changed and sent to the DVR2000E but not sent to EEPROM, the changed
settings are lost if DVR2000E operating power is lost. When exiting MARATHON-DVR2000E-32 or closing
communication, you are asked if you want to save the settings to EEPROM. This question is asked even if no
settings changes were made.
When communication is enabled, setting changes are saved to EEPROM by clicking the EEPROM button. The
opportunity to save settings to EEPROM is also given through a dialog box when exiting MARATHON-DVR2000E-
32 or closing communication.
SETTING DEFINITIONS
Each of the six setting groups has a corresponding MARATHON-DVR2000E-32 screen. The settings of each
screen are categorized by one or more tabs. In the following paragraphs, settings are arranged and dened
according to the organization of the MARATHON-DVR2000E-32 screens and tabs.
System Conguration
The System Conguration screen consists of one tab labeled System Settings. Click the Congure button to
access the System Conguration screen or click Screens on the menu bar and click System Conguration.
System Settings
System settings are shown in Figure 5-8 and are described in the following paragraphs.
Sensing Voltage. This setting is used to congure the DVR2000E for either single-phase or three-phase sensing
voltage.
