COMMUNICATION PORT
A communication port is located on the rear panel
and consists of a female RS-232 (DB-9) connector.
The communication port serves as an interface for
programming (setup) of the DVR2000E. Figure 2-2
illustrates the location of the communication port.
Programming requires a standard 9-pin serial
communication cable connected between the
DVR2000E and an IBM-compatible PC or handheld
computer operating with MARATHON-DVR2000E-32
software. MARATHON-DVR2000E-32 is a Windows®
98/NT based communication software package that is
supplied with the DVR2000E. A detailed description
of MARATHON-DVR2000E-32 software is provided in
Section 5, MARATHON-DVR2000E-32 Software.
Figure 2-2. DVR2000E Communication Port Location
