Table 2-11. Underfrequency Adjustment Ranges
Underfrequency Adjust – LED 7 Blinking Slowly
Maximum Adjustment Range: 40 to 65 Hz
Increment: 0.1 Hz
LED Minimum Value Maximum Value
12 63.0 65.0
11 60.9 62.9
10 58.8 60.8
9 56.7 58.7
8 54.6 56.6
7 52.5 54.5
6 50.5 52.4
5 48.4 50.4
4 46.3 48.3
3 44.2 46.2
2 42.1 44.1
1 40.0 42.0
Table 2-12. Droop Adjustment Ranges
Droop Adjust – LED 8 Blinking Slowly
Adjustment Range: 0 to 10%
Increment: 0.25%
LED Minimum Value * Maximum Value *
12 9.25 10.00
11 8.5 9.00
10 7.75 8.25
9 6.75 7.50
8 6.00 6.50
7 5.25 5.75
6 4.25 5.00
5 3.5 4.00
4 2.75 3.25
3 1.75 2.5
2 1 1.5
1 0 0.75
* Minimum and maximum values may differ from the Table 2-12 values if
the value has been changed in MARATHON-DVR2000E-32 software.
MARATHON-DVR2000E-32 software has 0.01% resolution compared to
the 0.25 percent resolution of the HMI.
