Table 2-9. VAR Control Adjustment Ranges *
VAR Control Adjust – LED 6 Blinking Slowly
Maximum Adjustment Range: −100% (absorb) to +100%
(generate)
Increment: 1.0%
LED Minimum Value † Maximum Value †
12 84 100
11 67 83
10 51 66
9 34 50
8 17 33
7 1 16
6 -16 0
5 -33 -17
4 -49 -34
3 -66 -50
2 -83 -67
1 -100 -84
* Var/PF control is available only on DVR2000EC.
† Minimum and maximum values may differ from the Table 2-9 values if
the value has been changed in MARATHON-DVR2000E-32 software.
MARATHON-DVR2000E-32 software has 0.5 percent resolution compared
to the 1.0 percent resolution of the HMI.
Table 2-10. Power Factor Control Adjustment Ranges *
Power Factor Control Adjust – LED 6 Blinking Slowly
Maximum Adjustment Range: +0.6 (lag) to –0.6 (lead)
Increment: 0.01
LED Minimum Value † Maximum Value †
12 0.66 0.60
11 0.73 0.67
10 0.80 0.74
9 0.86 0.81
8 0.93 0.87
7 1.0 0.94
6 -0.94 -0.99
5 -0.87 -0.93
4 -0.80 -0.86
3 -0.74 -0.79
2 -0.67 -0.73
1 -0.60 -0.66
* Var/PF control is available only on DVR2000EC.
† Minimum and maximum values may differ from the Table 2-10 values if
the value has been changed in MARATHON-DVR2000E-32 software.
MARATHON-DVR2000E-32 software has 0.001 resolution compared to
the 0.01 resolution of the HMI.
