S
ection
2
Table 2-13. Stability Range Selection Settings
Stability Range Select – LED 9 Blinking Slowly
Adjustment Range per LED: 1
Frame/Poles LED Range Selected
12 N/A
11 N/A
10 N/A
9 N/A
Programmable 8 21
1,000/6 7 7
740/6 6 6
1,000/4 5 5
740/4 4 4
570/4 3 3
430/4 2 2
360/4 1 1
Table 2-14. Gain Adjustment Ranges
Gain Adjust – LED 10 Blinking Slowly
Maximum Adjustment Range:
0.5 to 4.5 kg for AVR and 0 to 100 kg for FCR
When the unit is operating in AVR, PF, and var modes, gain adjustments are
made to AVR kg. When in FCR mode, gain adjustments are made to FCR
kg. Front Panel increments: AVR kg = 0.01 FCR kg = 0.1
LED
Minimum Value * Maximum Value *
AVR FCR AVR FCR †
12 4.17 11.1 4.50 12
11 3.84 10.1 4.16 11
10 3.50 9.1 3.83 10
9 3.17 8.1 3.49 9
8 2.84 7.1 3.16 8
7 2.50 6.1 2.83 7
6 2.17 5.1 2.49 6
5 1.84 4.1 2.16 5
4 1.50 3.1 1.83 4
3 1.17 2.1 1.49 3
2 0.85 1.1 1.16 2
1 0.5 0 0.84 1
* Minimum and maximum values may differ from the Table 2-14 values if the gain value has been changed in
MARATHON-DVR2000E-32 software.
† MARATHON-DVR2000E-32 software allows a maximum FCR kg setting of 1,000 kg. A kg setting of 12 or
more entered in MARATHON-DVR2000E-32 software will be reduced to 12 with the rst push of the HMI
“DOWN” pushbutton when adjusting FCR kg via the front panel.
Table 2-15. Fine Voltage Adjust Setting Ranges
Fine Voltage Adjust – LED #11 Blinking Slowly
Maximum Adjustment Range: -15% to +15%
Increment: 0.1V
The adjustment range for Fine Voltage Adjust is based on the ne
voltage adjustment band setting. The default adjustment range is
–10% to +10%. See Section 5, MARATHON-DVR2000E-32
Software for Windows® OS, Setting Denitions, Setting Adjustments
for information about the Fine Voltage Adjustment Band Setting.
