Chapter 4 EI system diagnosis Section 4 EI system troubleshooting
4—17
MALFUNCTION
CODE
DETECTED
ITEM
DETECTED FAILURE CONDITION
CHECK FOR
P0336
CKP
Noisy
Signal
After engine running, if the magneto rotor tooth’s error is happened
continuously by 10 times in 100 times test cycle,the code P0336 is
indicated.
CKP Sensor wiring and mechanical parts.(CKP Sensor leadwire coupler
connection)
P0335
No
Signal
After engine running, if the CKP Sensor signal does not reach ECU for
more than 0.5 sec., the code P0335 is indicated.
CKP Sensor wiring and mechanical parts.
P2301
IG coil
Circuit Short
High
After engine running, if ignition coil signal open or is happened the
high/ground short fault for 1 second by5 times in10 times test cycle,the
code P2301 is indicated.
Ignition coil,wiring/coupler connection,power supply from the battery.
P2300
IG coil Circuit
Open/Short Low
After the engine starts, if there are 5 1-second short-circuit to ground
faults in 10 test cycles, P2300 is displayed
Ignition coil, circuit plug, power supply circuit
P1693
Engine speed
outCircuit Short Low
After engine running, if Engine speed out Circuits happened the ground short
fault for 1 second by 5 times in 10 times test cycle, the code P1693 is
indicated
lead wire / coupler connection.
P1694
Engine speed
outCircuit Short High
After engine running, if Engine speed out Circuitis happened the High short
fault for 1 second by 5 times in 10 times test cycle, the code P1694 is
indicated
lead wire / coupler connection.
P0500
Speed sensor
Malfunction
Motorcycle speed＜10km/h
Water temperature＜20℃
MAP&IAT pressure＞40kpa
20%＜TPSopen angle＜100%
2,000rpm＜Engine speed ＜6,000rpm
If the above conditions are maintained for 32.5sec.and more,
The code P0500 is indicated
Speedo sensor,wiring/coupler connection to ECU
P0505
ISC Error
After engine running, if idle speed is different to 500 rpm from the
specified range in 25 seconds test cycle,the code P0505 indicated.
Idle speed control solenoid, wiring / coupler connection.
P0562
Batter
y
Voltag
e
Low
The battery voltage should be the following 9 V
≤Batteryvoltage
Without the above range for 3.125 sec. And more,P0562 is indicated.
Battery,wiring / couplerconnection to ECU.
P0563
High
The battery voltage should be the following.
Battery voltage ≤16V
Without the above range for 3.125 sec. And more,P0563 indicated.
Battery, wiring / couplerconnection to ECU.
