Chapter 6 Chassis section 3 Front and rear brakes
6—6
Section 3 Front and rear brakes
Structure
Fig 5.3.1
Warning:
The brake system uses glycol based DOT4 hydraulic oil.
Do not use and mix different grades of brake fluid, such as silicon based or petroleum
based brake hydraulic oil.
Do not use brake fluid in old, used or unsealed containers.
Never reuse the residual brake fluid after maintenance and the brake fluid stored for a
long time.
When storing brake fluid, keep the container completely sealed away from children.
When filling the brake fluid, be careful not to let dust into the brake system.
When cleaning brake parts, new brake fluid should be used.
Never use cleaning solvents.
Contaminated brake discs and friction discs can degrade braking performance.
Discard the contaminated friction disc and clean the brake disc with a good brake
cleaner or neutral detergent.
