Chapter 7 Electrical system, Section 6 Lamp
7
-
13
Section 5 Switches
Measure each switch for continuity using a tester. If any abnormality is found, replace the
respectiveswitch assemblies with new ones.
Pocket tester :09900
-
25002
IGNITION SWITCH
R B Br Br/
W
ENGINE STOP
B O/W
STARTER
Y/R O/W
DIMMER
Y/W B W Bl
PASSING
FRONT BRAKE SWITCH
B G/Y
PUSH
TURN SIGNAL
Sb O Gr
RR BRAKE SWITCH
B G/Y
PUSH
HORN
G Lg
PUSH
SIDE STAND SWITCH
B/W G
CLUTCH SWITCH
G G/R
PUSH
