Chapter 8 Information service Section 4 Service data
8-26
SUSPENSION
Unit:mm
ITEM STANDARD LIMIT
Front fork stroke
121
———
Front fork spring free length ———
465
Front fork oil type
ISO VIG46, JSK2001 ———
Front fork oil level
125
———
Front fork oil capacity (each leg)
320
ml
———
Rear wheel travel
84
———
Swingarm pivot shaft runout
———
0.4
Rear shock absorber pre-load position
2 / 5 position ———
Rear shock absorber spring length
260
255
BRAKE+WHEEL
Unit:mm
ITEM STANDARD LIMIT
Rear brake pedal free travel
20—30
———
Rear brake pedal height
50
———
Brake disc thickness
Front
4 3
Brake disc runout
Front
———
0.3
Master cylinder bore
Front 12.7~12.727
Φ12.7
Φ15.87
———
Rear 15.87~15.913
Master cylinder piston diam
Front
12.641~12.684
Φ12.7
Φ15.87
———
Rear 15.811~15.838
Brake caliper cylinder bore
Front
(27~27.05) ×2,
(22.2~22.25) ×1
Φ27×2+Φ22.2×1
Φ34×1
———
Rear
(34.0~34.05)×1
Brake caliper piston diam
Front
(26.902~26.935) ×2,
(22.102~22.135) ×1
Φ27×2+Φ22.2×1
Φ34×1
———
Rear
(33.902~33.935)×1
Brake fluid type
DOT4
———
Wheel rim runout
Axial ———
2.0
Radial ——— 2.0
Wheel axle runout
Front ——— 0.25
Rear ——— 0.25
Wheel rim size
Front
90/90-17 ———
Rear
100/70-17 ———
