Engine oil and oil filter
The engine oil should be replaced when the engine is
hot. Replace the oil filter element and replace the oil at the
same time according to the time specified on the regular
maintenance table.
Replace the engine oil
Keep the motorcycle parked vertically.
Place an oil pan under the engine and remove the oil
drain plug ① on the engine filter cover (there are three
bolts around. Do not remove the neutral positioning pin
bolts to drain the oil, so as not to miss the top pin and
spring, resulting in empty The gear is hard to find.) and the
fuel filler cap ② to drain the engine oil. As shown in Fig.
2.2.19.
Tighten the oil drain plug ① according to the specified
torque, and inject new oil through the oil filler port. When
changing the oil (when there is no need to change the oil
filter), the engine can be filled with approximately 850 ml
of oil. For engine oil graded according to API, SE or SF
should be used. Its viscosity is SAE10W-30.
Drain plug：28N.m（2.8kg.m）
Screw on the fuel filler cap ②.
Start the engine, and allowed to run at idle speed for
several minutes.
Stop the engine, wait for about 1 minute, and then
check the oil level through the sight glass ③.
If the oil level is lower than the "L" mark, it should be
added to the proper oil level.
As in Fig.2.2.20
Replace the oil filter
Drain the engine oil according to the instructions in
the procedure for changing the engine oil.
First remove the nut, and then remove the oil filter
element cover ④. Remove the oil filter element ⑤ and
replace it with a new one. Install the oil filter cover ④, and
then tighten the nut firmly.As in Fig.2.2.21
to the instructions in the engine oil
replacement procedure.
As in Fig. 2.2.22
Engine oil viscosity and grade ：
SAE 10W-40/SE or SG（API）
Engine oil requirement:
Replacement of engine oil: 850ml (mL)
Replace engine oil and filter element:
950ml (ml)
Replacement of oil and filter: 950ml (mL)
Engine heavy maintenance: 1300ml
Fig.2.2.19
Fig.2.2.20
Fig.2.2.21
Fig.2.2.22
