Chapter 8 Information service Section 4 Service data
8-25
ECU Fuse sizeECU
REC. / REG. / IGN 15 A
ECU / M.RELAY
ECU
15 A
FAN
15 A
ABS PUMP 25 A
ABS ECU 15A
ABS IGN 5A
SPARE
25 A
15 A
15 A
15 A
15A
5A
WATTAGE
Unit:W
ITEM SPECIFICATION
Head lamp LED TYPE 12V 22.4W
Position lamp LED TYPE 12V 2.4W
License lamp LED TYPE 12V 0.4W
Brake/Tail lamp/ LED TYPE 12V 2W/0.4W
Turn signal lamp
R10W 12V 10W
Speedometer lamp LED TYPE 12V 2W
Engine warning lamp LED TYPE 12V 0.1W
Turn signal indicator lamp
LED TYPE 12V 0.1W
High beam indicator lamp LED TYPE 12V 20W
Odometer/ Trip meter/ clock//
/
Fuel meter/ Coolant temp. meter/
LED TYPE 12V 0.1W
Neutral indicator lamp LED TYPE 12V 0.1W
※ LED: Light Emitting Diode
LCD: Liquid Crystal Display
Donotuseexceptthespecifiedbulb(Wattage).
